6.4 Commands and Responses
E5CK
6–13
Parameter No. Parameter Data Setting and Monitor Range Mode
00 Pattern No. *2 0 to number of patterns -1 *2
01 Step No. monitor *1 0 to number of steps -1
63 Standby time monitor *1 0.00 to 99.59
02 Pattern elapsing time monitor *1 0.00 to 99.59
eve
03 Pattern execution count monitor *1 0 to 9999
60 Number of steps 1 to 16
05 Step 0 SP/Target SP 0 SP lower limit to SP upper limit
06 Ramp rate 0 0 to 9999
07 Step 0 time/Soak time 0 0.00 to 99.59
08 Step 1 SP/Target SP 1 SP lower limit to SP upper limit
09 Ramp rate 1 0 to 9999
10 Step 1 time/Soak time 1 0.00 to 99.59
11 Step 2 SP/Target SP 2 SP lower limit to SP upper limit
12 Ramp rate 2 0 to 9999
13 Step 2 time/Soak time 2 0.00 to 99.59
14 Step 3 SP/Target SP 3 SP lower limit to SP upper limit
15 Ramp rate 3 0 to 9999
16 Step 3 time/Soak time 3 0.00 to 99.59
17 Step 4 SP/Target SP 4 SP lower limit to SP upper limit
18 Ramp rate 4 0 to 9999
19 Step 4 time/Soak time 4 0.00 to 99.59
20 Step 5 SP/Target SP 5 SP lower limit to SP upper limit
21 Ramp rate 5 0 to 9999
22 Step 5 time/Soak time 5 0.00 to 99.59
Program
23 Step 6 SP/Target SP 6 SP lower limit to SP upper limit
24 Ramp rate 6 0 to 9999
25 Step 6 time/Soak time 6 0.00 to 99.59
26 Step 7 SP/Target SP 7 SP lower limit to SP upper limit
27 Ramp rate 7 0 to 9999
28 Step 7 time/Soak time 7 0.00 to 99.59
29 Step 8 SP SP lower limit to SP upper limit
30 Step 8 time 0.00 to 99.59
31 Step 9 SP SP lower limit to SP upper limit
32 Step 9 time 0.00 to 99.59
33 Step 10 SP SP lower limit to SP upper limit
34 Step 10 time 0.00 to 99.59
35 Step 11 SP SP lower limit to SP upper limit
36 Step 11 time 0.00 to 99.59
37 Step 12 SP SP lower limit to SP upper limit
38 Step 12 time 0.00 to 99.59
39 Step 13 SP SP lower limit to SP upper limit
40 Step 13 time 0.00 to 99.59
*1 Reading only is possible.
*2 Can be used in either the level 0 or program modes.
Read only during program run
