Omron E5CK User Manual

CHAPTER 6 USING THE COMMUNICATIONS FUNCTION
E5CK
6–12
JReading/writing program parameters
F Reading parameters
Parameter
No.
Parameter
No.
Unit
No.
FCS
CR
Unit
No.
Read data FCS
CR
End
code
@
@
*
*
2B 2B 4B 2B 2B
2B 2B 4B 2B 2B2B
4
0000
4
Command
Response
F Writing parameters
Parameter
No.
Parameter
No.
Unit
No.
Write data FCS
CR
Unit
No.
Write data FCS
CR
End
code
@
@
*
*
2B 2B 4B 2B 2B
2B 2B 4B 2B 2B2B
5
5
Command
Response
Parameters relating to the program of the specified unit are read or writĆ
ten.
Ă• Writing is possible only during remote operation.
Ă• Reading is impossible during execution of autoĆtuning.
Ă• For details on parameters in each setting level, see the lists for each setĆ
ting level on pages 6Ć13 to 6Ć14.

Omron E5CK Specifications

General

Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP20
Control Type	PID
Input Type	Thermocouple, RTD
Output Type	Relay, Voltage, Current
Power Supply Voltage	100 to 240 VAC
Mounting Type	Panel
Display Type	Digital
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Dimensions	48 x 48 x 78 mm
Ambient Operating Humidity	25% to 85% RH
