6.4 Commands and Responses
E5CK
6–11
F A group
Bit Description [1] [0]
0 Heating side output ON OFF *1
1 Cooling side output ON OFF
2 Alarm output 1 ON OFF *2
3 Alarm output 2 ON OFF *2
4 Alarm output 3 ON OFF *2
5 LBA output ON OFF *2
6
7 Run/Reset Reset Run
8 Auto/Manual Manual Auto
9 Remote/Local Remote Local
10
11 AT AT execution OFF
12 Hold During hold OFF
13
14
15
F B group
Bit Description [1] [0]
0 Setting level 1 0
1
2 Control output 1 type Linear Pulse
3
4
5 Input error ON OFF
6 A/D converter error ON OFF
7
8
9
10
11 Time signal 1 output ON OFF *2
12 Time signal 2 output ON OFF *2
13 Ramp/soak Ramp Soak
14 Program end ON OFF *4
15 During standby ON OFF
*1 Always OFF" at linear output
*2 Always OFF" when output is not assigned
*3 When the ON time during control output is less than 190 ms, the heater current to which
1" is set and the previous current value is held.
*4 ON" while the No.2 display indicates [
]. For details on the [ ] indication, see
page 4Ć15.
To return to setting level 0 from setting level 1, issue the software reset" command.
