Omron E5CK

APPENDIX
E5CK
A–10
MODEL LIST
Description Type Name Specification
Base unit E5CK-TAA1 AC100-240 Base Unit
E5CK-TAA1-500 AC100-240 Base Unit with terminal cover
E5CK-TAA1 AC/DC24 Base Unit
E5CK-TAA1-500 AC/DC24 Base Unit with terminal cover
Output module E53-R4R4 Relay/relay
E53-Q4R4 Pulse (NPN)/relay
E53-Q4HR4 Pulse (PNP)/relay
E53-C4R4 Linear (4 to 20mA)/relay
E53-C4DR4 Linear (0 to 20mA)/relay
E53-V44R4 Linear (0 to 10V)/relay
E53-Q4Q4 Pulse (NPN)/pulse (NPN)
E53-Q4HQ4H Pulse (PNP)/pulse (PNP)
Option module E53-CK01 RS-232C
E53-CK03 RS-485
E53-CKB Event input : 1 point
E53-CKF Transfer output (4 to 20mA)
Terminal cover E53-COV07 Terminal cover for E5CK-T
The output unit is required for E5CK-TAA1 (including -500). For details on the output unit, see page 2-3.
When adding on the option unit, also see the option unit list on page 2-3.
