CHAPTER 3 BASIC OPERATION
E5CK
3–8
Ă• The control period is set in the control period (heat)" parameter (level
1 mode). The control period (heat)" parameter is factoryĆset to 20:20
seconds." The control period (cool)" output function is not assigned.
(the control period (cool)" parameter cannot be set.)
All of the above settings in this example are factory settings. In this examĆ
ple, let's check the parameter settings.
In this example, the parameters are set as follows:
control output 1 assignment" = control output (heat)"
auxiliary output 1 assignment" = alarm output 2"
direct/reverse operation" = reverse operation"
control period" = 20 secs"
(1) Select the menu display, and select ĂĂĂ : setup mode" using the
or keys. For details on selecting the menu display, see page
1Ć10.
(2) Press the
key for one second minimum to enter the setup mode.
The top parameter in the setup mode
: input type" is displayed.
(3) Press the
key until [ ] (control output 1 assignment" paĆ
rameter) is displayed. Default is [
].
(4) As the setting in this example is to be left as it is, press the
key
twice. The display changes to [ ] (auxiliary output 1 assignĆ
ment" parameter). Default is [ ].
(5) As the setting in this example is to be left as it is, press the key
until [
] (direct/reverse operation" parameter) is displayed.
Default is [
].
(6) As the setting in this example is to be left as it is, press the
or
keys to select : level 1 mode". For details on selecting the menu
display, see page 1Ć7.
(7) Press the key for one second minimum to enter the level 1 mode.
The top parameter in the level 1 mode ĂĂĂĂ
: Proportional band" is
displayed.
(8) Press the key until [ĂĂĂĂ ] (control period (heat)" parameter)
is displayed. Default is 20". As the setting in this example is to be left
as its is, quit key operation.
JControl period
Setting Example
1 second min.
1 second min.
1 second min.
To Next Page
