CHAPTER 3 BASIC OPERATION
E5CK
3–12
Alarm 2 is output when the temperature exceeds alarm value 2 proĆ
grammed to the SP. Parameter factory settings for alarm type 2," alarm
hysteresis" and close in alarm/open in alarm" are used.
In this example, the related parameters are set as follows:
alarm type 2" = 2: upperĆlimit"
alarm value 2" = (set in program setting)
alarm hysteresis: = 0.02"
close in alarm/open in alarm" = 
: close in alarm"
In this example, let's check the alarm type.
(1) Select the menu display, and select ĂĂ : setup mode" pressing the
or keys. For details on selecting the menu display, see page
1Ć9.
(2) Press the
key to enter the setup mode. The top parameter in the
setup mode 
: input type" is displayed.
(3) Press the
key until [ ] (alarm type 2" parameter) is disĆ
played. Default is 2: upper limit".
Setting Example
1 second min.
