Omron E5CK User Manual

E5CK
5–7
Pattern No.
Conditions of Use
The “number of patterns” parameter must
be set to a value greater than “2”.
Ă• This parameter can be set only when the controller is reset.
Ă• Displays the execution pattern during program operation, and the set pattern after
the controller is reset.
Ă• This parameter can also be used in the program mode.
Setting Range Unit Default
0 to number of patterns -1 None 0
ĂRelated description
3.5 Setting Patterns (page 3Ć14)
ĂRelated parameters
All parameters in the program mode
Number of patterns" (expansion mode)
Step No. monitor
Ă• Monitors the current step No. (This parameter is reset to 0" when the controller is
reset.)
Monitor Range
Unit
0 to Number of steps-1 None
ĂRelated description
4.4 Program Operation (page 4Ć13)
ĂRelated parameters
Hold" Advance" (level 0 mode)
Level 0 Mode
Function
Setting
See
Function
Monitor
See

Omron E5CK Specifications

General

Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP20
Control Type	PID
Input Type	Thermocouple, RTD
Output Type	Relay, Voltage, Current
Power Supply Voltage	100 to 240 VAC
Mounting Type	Panel
Display Type	Digital
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Dimensions	48 x 48 x 78 mm
Ambient Operating Humidity	25% to 85% RH
