SPECIFICATIONS
E5GN
A–3
JCharacteristics
Indication accuracy
Thermocouple:
(±0.5% of indication value or ±1_C, whichever is greater) ±1 digit max. (*1)
Platinum resistance thermometer:
(±0.5% of indication value or ±1_C, whichever is greater) ±1 digit max.
Analog input: ±5%FS±1 digit max.
Hysteresis 0.1 to 999.9EU (in units of 0.1EU)
Proportional band (P) 0.1 to 999.9EU (in units of 0.1EU)
Integral time (I) 0 to 3999 (in units of 1 second)
Derivative time (D) 0 to 3999 (in units of 1 second)
Control period 1 to 99 (in units of 1 second)
Manual reset value 0.0 to 100.0% (in units of 0.1%)
Alarm setting range -1999 to 9999 (decimal point position dependent on input type)
Sampling period 500 ms
Insulation resistance 20 MΩ min. (by 500 VDC megger)
Dielectric strength 2000 VAC 50 or 60 Hz 1min
Malfunction vibration 10 to 55 Hz, 10 m/s2 for 10 min. each in X, Y and Z directions
Vibration resistance 300 10 to 55 Hz, 20 m/s2 for 2 hrs. each in X, Y and Z directions
Malfunction shock 200 m/s2 max. 3 times each in 3 axes, 6 directions (relay: 100 m/s2)
Shock resistance 300 m/s2 max. 3 times each in 3 axes, 6 directions (relay: 100 m/s2)
Weight Approx. 90 g Adapter: approx. 10g
Protective structure
Front panel: NEMA4X for indoor use (equivalent to IP66),
Rear case: IP20, terminals: IP00
Memory protection EEPROM (non-volatile memory) (number of writes: 100,000)
*1 The indication of K thermocouples in the Ć200 to 1300_C range, T and N thermocouples at a temperature of Ć100_C or less,
and U and L thermocouples at any temperature is ±2_C±1 digit maximum. The indication of B thermocouples at a temperaĆ
ture of 400_C or less is unrestricted.
The indication of R and S thermocouples at a temperature of 200_C or less is ±3_C±1 digit maximum.
