Omron E5GN - Setting the SP; Changing the SP

CHAPTER 3 BASIC OPERATION
E5GN
3–10
3.6 Setting the SP
The operation level" is displayed when the E5GN is turned ON. The left
display (No.1 display) displays the process value, and the right display
(No.2 display) displays the set point.
Ă• The set point cannot be changed when the operation/adjustment
protection" parameter is set to 3". For details, see 4.8 Using the Key
Protect Levels."
Ă• To change the set point, press the or keys in the PV/SP"
parameter (operation level), and set the desired set value. The new set
point is selected two seconds after you have specified the new value.
In this example, let's change the set point from 0_C" to 200_C".
(1) Normally, the PV/SP" parameter is displayed. The set point is 0_C".
(2) Press the or keys until the set point changes to 200_C".
Operation level
JChanging the SP
Operation Procedure
Operation level
