To set heating and cooling control, set the standard/heating and cooling",
dead band" and cooling coefficient" parameters.
• Setting heating and cooling control
standard/heating and cooling" = heating and cooling"
(1) Press the key for at least three seconds to move from the operaĆ
tion level" to the initial setting level".
(2) Select standard heating and cooling control" in the initial setting
level".
: Standard control
: Heating and cooling control
• Setting dead band
Dead band" = 5"
(1) Select dead band" in the adjustment level".
(2) Use the keys to set the parameter to 5.0".
The setting range is Ć199.9 to 999.9.
• Setting cooling coefficient
Cooling coefficient = 10
(1) Select cooling coefficient" in the adjustment level".
In this example, set the parameter to 10".
(2) Use the keys to set the parameter to 10.00".
The setting range is 0.01 to 99.99.
JSetup
Operation Procedure
Standard/heating
and cooling
Initial setting level
Operation Procedure
Dead band
Adjustment level
Operation Procedure
Cooling
coefficient
Adjustment level
