APPENDIX
E5GN
A–2
SPECIFICATIONS
JRatings
Supply voltage 100 to 240 VAC, 50/60 Hz 24 VAC, 50/60 Hz/24 VDC
Operating voltage range 85 to 110% of rated supply voltage
Power consumption 7VA 4VA/2.5W
Sensor input Thermocouple : K, J, T, E, L, U, N, R, S, B
Platinum resistance thermometer : Pt100, JPt100
Non-contact temperature sensor : K10 to 70_C, K60 to 120_C, K115 to 165_C,
K160 to 260_C
Voltage input: 0 to 50 mV
Control
output
Relay output SPST-NO, 250 VAC, 2A (resistive load), electrical life : 100,000 operations
Min. applicable load 5V 10 m
Voltage output Output voltage 12 VDC (PNP), max. load current 21 mA, with short-circuit protection
circuit
Alarm output SPST-NO, 250 VAC, 1A (resistive load), electrical life : 100,000 operations
Min. applicable load 1V 1 mA
Control method 2-PID or ON/OFF control
Setting method Digital setting using front panel keys
Indication method 7-segment digital display and single-lighting indicator
Other functions According to controller model
Ambient temperature -10 to 55_C (with no condensation or icing)
Ambient humidity Relative humidity 25 to 85%
Storage temperature -25 to 65_C (with no condensation or icing)
Altitude 2,000 m or less
Recommended fuse T2A, 250 VAC, time lag, low shut–off capacity
Installation environment Installation Category II, Pollution Class 2 (IEC 61010–1 compliant)
* For the setting ranges for each input, see page AĆ9.
