This level is for using the E5GN to its maximum. You can move to this level by entering the passĆ
word (Ć169") in the initial setting level.
Password input
set value “1201”
Advanced
function setting level
Calibration level
Control in progress
Control stopped
Power ON
Operation
level
Adjustment
level
Initial setting level
Commu-
nications
setup level
1 second
min.
key
less than
1 sec.
key
less than
1 sec.
key
Control stop
3 seconds min.key
Theh PV display flashes
after one second.
key
Password input
set value “-169”
Ă• The parameters in this level can be used when iniĆ
tial setting/communications protection" is set to 0".
Ă• The move to calibration level" can be moved to by
entering the password.
Ă• To switch between setting levels, press the
key.
Ă• To change setting values, press the
keys.
Advanced Function Setting Level
Advanced function setting level
Parameter initialize
Page
5-26
5-26
5-27
5-28
5-29
5-29
5-30
5-30
5-31
5-31
5-32
5-32
5-33
5-33
Alarm 1 hysteresis
Alarm 1 open in alarm
Standby sequence reset
method
MultiĆSP uses
Move to calibration
level
Automatic return of
display mode
Manipulated variable
display
Additional PV display
Input digital filter
MV upper limit
α
ST stable range
MV lower limit
SP ramp set value
5-34
Alarm 1 latch
5-34
Protect level move time
5-35
Output input error
5-35
Cold junction
compensation method
5-36
MB command logic
switching
