Omron E5GN User Manual

CHAPTER 4 APPLIED OPERATION
E5GN
4–8
4.3 Setting Scaling Upper and Lower Limits (analog
input)
Ă• When an analog input (voltage input) is selected, scaling matched to the
control is possible.
Ă• Scaling is set in the scaling upper limit", scaling lower limit" and decĆ
imal point" parameters (initial setting level). These parameters cannot
be used when temperature input type is selected.
Ă• The scaling upper limit" parameter sets the physical quantity to be
expressed by the upper limit value of input, and the scaling lower limit"
parameter sets the physical quantity to be expressed by the lowerĆlimit
value of input. The decimal point" parameter specifies the number of
digits past the decimal point.
Ă• The following figure shows a scaling example of 0 to 5 mV input. After
scaling, the humidity can be directly read.
Input
(0 to 50 mV)
Readout
(humidity)
Upper-limit value (95.0%)
Lower-limit value (10.0%)
0
100%FS
50mV
0mV
In this example, let's set the scaling upperĆ and lowerĆlimits so that inputs
0 to 50 mV are 10.0% to 95.0%.
(1) Press the key for at least three seconds to move from the operaĆ
tion level" to the initial setting level".
(2) Select scaling upper limit" by pressing .
(3) Press the or key to set the parameter to 950".
(4) Select scaling lower limit" by pressing .
(5) Press the or key to set the parameter to 100".
(6) Select the decimal point position by pressing .
(7) Press the or key to set the parameter to 1".
(8) To return to the operation level" press the key for at least one
second.
JAnalog input
Scaling
upper
limit
Scaling
lower limit
Decimal
point
Operation Procedure
Input type
Initial setting level
Scaling upper
limit
Scaling lower
limit
Decimal point
