SENSOR INPUT SETTING RANGES
E5GN
A–9
SENSOR INPUT SETTING RANGES
Input type Specifications Set Value Input Temperature Range
Platinum Platinum 0 -200 to 850 (_C) / -300 to 1500 (_F)
resistance resistance
Pt100 1 -199.9 to 500.0 (_C) / -199.9 to 900.0 (_F)
thermometer
input type
thermometer
2 0.0 to 100.0 (_C) / 0.0 to 210.0 (_F)
input type
3 -199.9 to 500.0 (_C) / -199.9 to 900.0 (_F)
JPt100
4 0.0 to 100.0 (_C) / 0.0 to 210.0 (_F)
Input type Specifications Set Value Input Temperature Range
Thermocou- Thermocouple
K 0
-200 to 1300 (_C) / -300 to 2300 (_F)
ple input type
1
-20.0 to 500.0 (_C) / 0.0 to 900.0 (_F)
J 2
-100 to 850 (_C) / -100 to 1500 (_F)
3
-20 to 400.0 (_C) / 0.0 to 750.0 (_F)
T 4
-200 to 400 (_C) / -300 to 700 (_F)
E 5
0 to 600 (_C) / 0 to 1100 (_F)
L 6
-100 to 850 (_C) / -100 to 1500 (_F)
U 7
-200 to 400 (_C) / -300 to 700 (_F)
N 8
-200 to 1300 (_C) / -300 to 2300 (_F)
R 9
0 to 1700 (_C) / 0 to 3000 (_F)
S 10
0 to 1700 (_C) / 0 to 3000 (_F)
B 11
100 to 1800 (_C) / 300 to 3200 (_F)
Non-contact
K10 to 70_C 12
0 to 90 (_C) / 0 to 190 (_F)
temperature
K60 to 120_C 13
0 to 120 (_C) / 0 to 240 (_F)
sensor ES1A
K115 to 165_C 14
0 to 165 (_C) / 0 to 320 (_F)
K160 to 260_C 15
0 to 260 (_C) / 0 to 500 (_F)
Analog input
0 to 50mV 16
One of following ranges depending on the results of
scaling: -1999 to 9999, -199.9 to 999.9
The applicable standards for each of the above input ranges are as follows:
K, J, T, E, N, R, S, B : JIS C1602Ć1995, IEC 584Ć1
L : FeĆCuNi, DIN 43710Ć1985
U : CuĆCuNi, DIN 43710Ć1985
JPt100 : JIS C 1604Ć1989, JIS C 1606Ć1989
Pt100 : JIS C 1604Ć1997 IEC 751
Default is set value 0".
Control Range
Ă• Platinum resistance thermometer and thermocouple input
-20_C of temperature setting lower limit to +20_C of the temperature setting upper limit
Or,
-40_F of temperature setting lower limit to +40_F of the temperature setting upper limit
Ă• ES1A input
Same as input indication range
Ă• Analog input
-5% to +105% of scaling range
