3 Configuration
3 - 42
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
 Wide View
• Long-distance: FZ-SQ100F
• Short-distance: FZ-SQ100N
*1. The mounting brackets can be connected to either side.
Additional Information
We have the 2D CAD data or 3D CAD data.
You can download CAD data from www.fa.omron.co.jp.
1
(49)
338
(94.8)
44
Mounting Bracket *1
1/4-20UNC Depth: 6
Four, M4 Depth: 6
46
45
67
Optical
axis
8
94.8 32
20
Polarizing
Filter Attachment
20
(25)
38
42
20±0.1
Two, 4.5 dia.
Mounting Hole Dimensions
Tightening torque: 1.2 N·m
(Unit: mm)
