Omron SYSMAC FH Series Hardware Setup Manual

3 Configuration
3 - 76
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
 DVI-Analog Conversion Cable for Touch Panel Monitor: FH-VMDA
*1. Cable is available in 2 m/5 m/10 m.
 RS-232C Cable for Touch Panel Monitor: XW2Z-PP-1
*1. Cable is available in 2 m/5 m/10 m.
 USB Cable for Touch Panel Monitor: FH-VUAB
*1. Cable is available in 2 m/5 m.
17-pin DVI connector
15-pin D-SUB connector
45±5
L
*1
45±5
10±2
L
*1
40
9-pin D-SUB connector 9-pin D-SUB connector
11.5 max.
45±5
45±5
12±0.25
L
*1
12±0.25
4-pin USB B type connector
4-pin USB A type connector
15
8 max.
10.5 max.
10±2
