Omron SYSMAC FH Series

5 - 45
5 Setup and Wiring
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
5-8 Installation in a Control Panel
5
5-8-3 FH-L Series
• Dimensions of DIN rail mounting bracket: FH-XDM-L
76
59
Four, 4.6 dia.
3
157.2
102.2
13
110 100
(Unit: mm)
