Vision System FH/FZ5 series Hardware Setup Manual (Z366)
c) [Output]
Applicable signals:
BUSY0, RUN/BUSY1, OR0 to 1, GATE0 to 1, ERROR, DO0 to 15, READY
0 to 1
d) [Output]
Applicable signals:
STGOUT0 to 3
When STGOUT0 to 3 are used, connect the terminal.
Item Specifications
Internal circuit
dia
gram
Item Specifications
Internal circuit
dia
gram
Each output terminal
Load
COM OUT
+
COM OUT
COM IN
Load
+
Each output
terminal
FZ5-600 Series/
FZ5-1100 Series:
COM OUT
COM IN
Each output
terminal
Load
+
Load
FZ5-800 Series/
FZ5-1200 Series:
