6 I/O Interface
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
6-1 Parallel Interface
6
6-1-7 Other (Parallel Converter Cable)
Note 1. PIN_No.1 of CN4 is unified in 1 system with shorting COMIN0-2 of FH series.
2. PIN_No.2 of CN4 is unified in 1 system
with shorting COMOUT0-3 of FH series.
B22 --- DO10 --- 27 DO10
B23 DO12 --- 29 DO12
B24 DO14 --- 31 DO14
B25 DO15 --- 32
DO15
FZ-VP side connection connector FH side connection Connector
Pin No.
Signal name
Pin No.
Signal name
CN3 CN4 CN1 CN2
