Omron SYSMAC FH Series Hardware Setup Manual

3 - 9
3 Configuration
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-1 Sensor Controller
3
3-1-2 FH-L Series
*1. Existing third class grounding
Power-supply voltage 20.4 VDC to 26.4 VDC
Current
co
nsump-
tion
When con-
nected to a
C
ontroller
Connected to 2 cameras 3.5 A max. 3.7 A max.
Connected to 4 cameras --- 5.9 A max.
Connected to 8 cameras --- ---
When not
connected
to Controller
Connected to 2 cameras 1.5 A max. 1.7 A max.
Connected to 4 cameras --- 2.0 A max.
Connected to 8 cameras --- ---
Built-in FAN No
Usage Envi-
ronment
Ambient temperature range Operating: 0°C to 55°C
Storage: -25 to +70°C
Ambient humidity range Operating and Storage: 10 to
90%RH (with no condensation)
Ambient atmosphere No corrosive gases
Vibration tolerance 5 to 8.4 Hz with 3.5 mm amplitude, 8.4 to 150 Hz, acceleration
o
f 9.8 m/s
2
100 min each in X, Y, and Z directions (10 sweeps of 10 min
each = 100 min total)
Shock resistance
Impact force: 150 m/s
2
Test direction: up and down/front and behind/left and right
Noise
immunity
Fast Transient Burst • DC power
Direct infusion: 2kV, Pulse rising: 5ns, Pulse width: 50ns,
Burst continuation time: 15ms/0.75ms, Period: 300ms,
Application time: 1 min
• I/O line
Direct infusion: 1kV, Pulse rising: 5ns, Pulse width: 50ns,
Bu
rst continuation time: 15ms/0.75ms, Period: 300ms,
Application time: 1 min
Grounding
Type D grounding (100 Ω or less grounding resistance)
*1
External
Features
Dimensions 200 mm × 80 mm × 130 mm
Weight Approx. 1.5 kg Approx. 1.5 kg
Degree of protection IEC60529 IP20
Case materials
PC
Sensor Controller Series FH-L series
Type Lite Controller
Sensor Controller Model FH-L550 FH-L550-10
