Setting name Setting description
De-
fault
value
Setting
range
Unit
Update
timing
Remarks
Ch1 Filter 1
Moving Aver-
age Count
Set the moving aver-
age count for the mov-
ing average filter 1.
0 0 to 4096
times Immedi-
ately
Set this parameter to 0 to
disable the moving aver-
age filter.
Ch2 Filter 1
Moving Aver-
age Count
Ch3 Filter 1
Moving Aver-
age Count
Ch4 Filter 1
Moving Aver-
age Count
Ch1 Filter 2
Moving Aver-
age Count
Set the moving aver-
age count for the mov-
ing average filter 2.
0
0 to 4096
times
Ch2 Filter 2
Moving Aver-
age Count
Ch3 Filter 2
Moving Aver-
age Count
Ch4 Filter 2
Moving Aver-
age Count

Precautions When You Change Set Values
If you use the actual system to adjust the values of settings that are designed to be updated imme-
diately after a change, change the values of only those settings and transfer them to the Unit. Note
that you need to restart the Unit if you change and transfer the values of settings that are designed
to be updated only after a restart.

Moving Average Filter Enable/Disable Setting
The moving average filters are disabled by default.
Set the moving average count for the filter to enable in the Unit operation settings to a value other
than 0 to enable the moving average filter
.
Set the moving average count for the filter to disable in the Unit operation settings to 0
to disable
the moving average filter
.
You can also enable/disable the moving average filter with the relevant bit in the Ch£ Operation
Command of I/O data. To enable/disable the moving average filter with the relevant bit, set the
moving average count for the filter to enable in the Unit operation settings to a value other than 0. If
the moving average is set to 0, the moving average filter will not be enabled even if the relevant bit
is set to enable. The relevant bit is Ch£ Moving Average Filter 1 Disable or Ch£ Moving Average
Filter 2 Disable.
Refer to Ch
£ Operation Command on page 7 - 11 for details on Ch£ Operation Command.
