Omron SYSMAC NX series User Manual

Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Ac-
ces
s
I/O allo-
cation
Data
attrib-
ute
5006 --- Digital Low-pass Filter
Cutoff Frequency
--- --- ---
--- --- --- ---
00 Number of Entries 4 4 --- USINT RO Not pos-
sible
---
01 Ch1 Digital Low-pass Fil-
ter Cutoff Frequency
0 0 to 9900
× 10
Hz
UINT R/W Not pos-
sible
N
02 Ch2 Digital Low-pass Fil-
ter Cutoff Frequency
0 0 to 9900
× 10
Hz
UINT R/W Not pos-
sible
N
03 Ch3 Digital Low-pass Fil-
ter Cutoff Frequency
0 0 to 9900
× 10
Hz
UINT R/W Not pos-
sible
N
04 Ch4 Digital Low-pass Fil-
ter Cutoff Frequency
0 0 to 9900
× 10
Hz
UINT R/W Not pos-
sible
N
• Refer to 8-5 Digital Filtering on page 8 - 18 for details on the function.
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Ac-
ces
s
I/O allo-
cation
Data
attrib-
ute
5007 --- Filter 1 Moving Average
Count
--- --- --- --- --- --- ---
00 Number of Entries 4 4 --- USINT RO Not pos-
sible
---
01 Ch1 Filter 1 Moving Aver-
age Count
0 0 to 4096 time
s
UINT R/W Not pos-
sible
N
02 Ch2 Filter 1 Moving Aver-
age Count
0 0 to 4096 time
s
UINT R/W Not pos-
sible
N
03 Ch3 Filter 1 Moving Aver-
age Count
0 0 to 4096 time
s
UINT R/W Not pos-
sible
N
04 Ch4 Filter 1 Moving Aver-
age Count
0 0 to 4096 time
s
UINT R/W Not pos-
sible
N
• Refer to 8-5 Digital Filtering on page 8 - 18 for details on the function.
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Ac-
ces
s
I/O allo-
cation
Data
attrib-
ute
5008 --- Filter 2 Moving Average
Count
--- --- --- --- --- --- ---
00 Number of Entries 4 4 --- USINT RO Not pos-
sible
---
01 Ch1 Filter 2 Moving Aver-
age Count
0 0 to 4096 time
s
UINT R/W Not pos-
sible
N
02 Ch2 Filter 2 Moving Aver-
age Count
0 0 to 4096 time
s
UINT R/W Not pos-
sible
N
03 Ch3 Filter 2 Moving Aver-
age Count
0 0 to 4096 time
s
UINT R/W Not pos-
sible
N
04 Ch4 Filter 2 Moving Aver-
age Count
0 0 to 4096 time
s
UINT R/W Not pos-
sible
N
Appendices
A - 49
NX-series Analog I/O Units User’s Manual for High-speed Analog Input Units (W592)
A-5 List of NX Objects
A
A-5-4 Other Objects
