Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Ac-
ces
s
I/O allo-
cation
Data
attrib-
ute
5005 --- Number of Samplings Set-
ting
--- --- --- --- --- --- ---
00 Number of Entries 4 4 --- USINT RO Not pos-
sible
---
01 Ch1 Number of Samplings
Setting
1 1, 2, 4, 5,
8, 10, 20,
25, 40,
50, 80,
100, 125,
200, 250,
400, 500,
625, or
1000
*1
time
s
UINT R/W Not pos-
sible
Y
02 Ch2 Number of Samplings
Setting
1 time
s
UINT R/W Not pos-
sible
Y
03 Ch3 Number of Samplings
Setting
1 time
s
UINT R/W Not pos-
sible
Y
04 Ch4 Number of Samplings
Setting
1 time
s
UINT R/W Not pos-
sible
Y
*1.
The meanings of the set values for Ch£ Number of Samplings Setting are as follows.
Set value Meaning
1 1 time
2 2 times
4 4 times
5 5 times
8 8 times
10 10 times
20 20 times
25 25 times
40 40 times
50 50 times
80 80 times
100 100 times
125 125 times
200 200 times
250 250 times
400 400 times
500 500 times
625 625 times
1000 1000 times
• Refer to 8-4 Number of Samplings Setting on page 8 - 8 for details on the function.
Appendices
A - 48
NX-series Analog I/O Units User’s Manual for High-speed Analog Input Units (W592)
