Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Ac-
ces
s
I/O allo-
cation
Data
attrib-
ute
5004 --- Disconnection Detection
Enable/Disable Setting
--- --- --- --- --- --- ---
00 Number of Entries 4 4 --- USINT RO Not pos-
sible
---
01 Ch1 Disconnection Detec-
tion Enable/Disable
FALSE TRUE or
F
ALSE
*1
--- BOOL
R/W Not pos-
sible
N
02 Ch2 Disconnection Detec-
tion Enable/Disable
FALSE TRUE or
FALSE
*1
--- BOOL
R/W Not pos-
sible
N
03 Ch3 Disconnection Detec-
tion Enable/Disable
FALSE TRUE or
FALSE
*1
--- BOOL
R/W Not pos-
sible
N
04 Ch4 Disconnection Detec-
tion Enable/Disable
FALSE TRUE or
FALSE
*1
--- BOOL
R/W Not pos-
sible
N
*1.
The meanings of the set values for Ch£ Disconnection Detection Enable/Disable are as follows.
Set value Meaning
FALSE Disable
TRUE Enable
• Refer to 8-6 Input Disconnection Detection on page 8 - 29 for details on the function.
Appendices
A - 47
NX-series Analog I/O Units User’s Manual for High-speed Analog Input Units (W592)
A-5 List of NX Objects
A
A-5-4 Other Objects
