Omron TM Collaborative Robot: Conveyor Tracking User’s Manual 18

Figure 4: Sensor Mode diagram

ETH Mode

ETH Mode is composed of a robot, an external camera, and light sourcing devices. Application diagram

of ETH Mode is shown in Figure 5.

Figure 5: ETH Mode diagram

* Currently, TM Conveyor Tracking only supports Sensor Mode by default. For purchase of ETH Mode license, consult with

your local representatives.
