• Data Type to access Output Area
Data type name: S_EIPOutput197
Type of derivative data type: Structure
Data Name Data Type
S_EIPOutput197 STRUCT
COMMANDS COMMAND
Example assignments of Variable Data Type for Output Area:
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
+0 Reserved
*1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1
TR
IG
*1
+1 Reserved
*1. For Bits other than TRIG, please refer to Output Assembly (Instance ID: 197) on page
A - 29.
• Data Type to access Input Area
Data type name: S_EIPInput102
Type of derivative data type: Structure
Data Name Data Type
S_EIPInput102 STRUCT
INFO_BITS BYTE
DIAGNOSTIC_SEQUENCE_COUNT BYTE
CONFIGURATION_SEQ_COUNT BYTE
RESERVED BYTE
DEVICE_STATUS Device Status
FAULT DINT
COUNTERS ARRAY[0..5]OF DINT
READ_CYCLE_REPORT ARRAY[0..3] OF INT
DECODE_CYCLE_REPORT ARRAY[0..3]OF DINT
DECODE_CYCLE_REPORT DINT
DECODE_DATA ARRAY[0..183] OF BYTE
Example assignments of Variable Data Type for Input Area:
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
+0 DIAGNOSTIC_SEQUENCE_COUNT INFO_BITS
+1 RESERVED CONFIGURATION_SEQ_COUNT
+2 Code reader Signal Status Information (Device_Status)
+3
+4 Code Reader Error Code Information (FAULT)
+5
+6 Read Counter Information (COUNTERS)
…
...
+11
3 Controlling Operation and Data Output with Ethernet
3 - 16
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
