8-26 Operator’s Manual – OPTI CCA-TS2
8 DIAGNOSTICS AND TROUBLESHOOTING
8.2.14 Checking the Ethernet Interface
Fig. 8-20 Ethernet Test
The purpose of this test is to check for proper
functioning of the Ethernet interface.
In the main menu, press <System Manager ->
Diagnostics>.
• Select the <Tests> tab.
•
Press <Ethernet> to start the test (Fig. 8-20).
• The system will send out data and check if they
are received (Fig. 8-21).
• Press
to return to the <System> screen
or
to return to the main menu
Fig. 8-21 Ethernet Test
