Operator’s Manual – OPTI CCA-TS2 1-9
1 INTRODUCTION
The reusable tHb Calibration Cassette (Fig. 1-19)
is used for the quarterly calibration of the OPTI
CCA-TS2 Analyzer (See Section 7.3 Quarterly
Maintenance - Performing tHb Calibration).
During calibration, the OPTI CCA-TS2 uses a
precision gas which is completely self-contained
in a disposable low-pressure bottle. The bottle is
inserted on the right side of the unit after scanning
the bar code (Fig. 1-20).
The TS2 will only work with gas bottles with a red
base (BP7162).
Congratulations!
You have just learned the basic components of the analyzer and are now ready to install your
system.
Gas Bottle
Fig. 1-20 Gas Bottle
tHb Calibration Cassette
Fig. 1-19 tHb Calibration Cassette
