MDI-4000 Series Seri
al Interface Manual
113
10.2.3
MDI-
4x
x0 Detailed V
iew
MDI-4100 and
MDI-4150 Dimens
ions
Dimensions:
W: 25.3 mm × D: 21
.0 mm × H: 9
.
7 mm
Weight:
Approx. 5.5 g
*
Height of the MDI-4100 and the MDI-4150
Figure
45
:
MDI-4100 and
MDI-4150 Mechani
cal Drawing
Product Label
21.6
0.1
21
0.5
3.9
0.3
2.5
0.1
( 4.5 )
( 2.4 )
Illumination LED Lens
Aiming LED lens
Camera Lens
25.3
0.3
3
*
MDI4150
1000001
/UF1xxB
Machine Screw M2
Depth 2.5
Pitch 0.4
Host Interface connector(12pin)
IRISO 9681-12
1
12
124
126
