4 SETUP INSTRUCTIONS

After having carried out an adjustment and before using the

wheelchair, make sure that all hardware is tight. Make sure

that all functions are secure before using the wheelchair.

The adjustments of your wheelchair must be made

by a health care professional. Inadequate adjustments can

cause wounds and/or damage to the user, the caregiver, the

wheelchair or the environment.

4.1 FOOTREST

4.1.1 LEGREST LENGHT ADJUSTMENT

Figure 1 : To change legrest length.

a) To adjust the length of all types of footrest (see; figure 1):

1. Remove the (A) adjustment screw, using a 7/16" wrench;

2. Adjust the telescopic tubing (C) at the needed length;

3. Put back the (A) screw and tighten firmly

TELESCOPIC

TUBING
