4 SETUP INSTRUCTIONS
inc All rights reserved
59
4.11 ANTI-TIPPERS
4.11.1 HEIGHT ADJUSTMENT
Figure 35-A : Anti-tipper height adjustment.
Push the (B) spring release button and slip the lower part of the anti-tipper upwards or
downwards to reach the height of 1 3/4 inches relatively to the floor. You can also use
the (A) spring release button (see; figure 35-A, B and C).
The adjustments of your wheelchair must be made
by a health care professional. Inadequate adjustments can
cause wounds and/or damage to the user, the caregiver, the
wheelchair or the environment.
A maximum of 1 3/4 inches between the floor and the anti-
tippers must be maintained at any time.
