4 SETUP INSTRUCTIONS
inc All rights reserved
60
Figure 35-B : Always keep a distance of 1 3/4 inches between the anti-tippers and the floor.
Figure 35-C : Engage the spring release button in the adjustment holes.
If the seat to floor height or the dimension of the rear wheels
were modified, the anti-tippers must be adjusted in order to
maintain the height of 1 3/4 inches between the anti-tippers
and the floor.
The anti-tippers must be well engaged and the spring
release button must arise from the adjustment hole.
1 3/4"
