Orthofab Tango - Inches Rear Wheels Brake

5 OPERATING INSTRUCTIONS
inc All rights reserved 80
5.7.4 12 INCHES REAR WHEELS BRAKE
The 12 inches rear wheel foot brake system, is activated by the caregiver, behind
the wheelchair, as shown in figure 52-A. There is no rear wheels adjustment.
To activate it, simply push with your foot on the central pedal, behind the
wheelchair (see; figure 52-A).
Figure 52-A : Foot brake system, applied.
To deactivate it, simply push with your foot at the top of the central pedal or pull
upwards the central pedal with your foot. You can also use your hand with one
of the (2) two handles positioned on each side of the central pedal
(see; figure 52-B).
Figure 52-B : Foot brake system, disengaged.
