5 OPERATING INSTRUCTIONS
inc All rights reserved
63
5.1.2 TO REMOVE AND/OR INSTALL
1. Follow the 5.1.1 section to swingaway the armrest from its (B) front socket
armrest support (see; figure 37).
2. Unscrew slightly the locking nut and the screw (G) from the (C) rear armrest
socket, using a 8 mm key and a 4mm Allen key. Pull upwards the armrest,
grabbing it by the (J) armrest upholstery to remove it completely from the (C) rear
armrest socket.
3. To replace the armrest, first insert the rear part of the armrest in the (C) rear
armrest socket.
4. Tighten the locking screw and nut (G) and position the armrest as describe in the
5.1.1 section above.
5. After you put back in place the armrest, make sure that it is locked correctly and
secure in the (B) front socket armrest support by trying to swingaway the armrest
using the (E) transfer handle.
5.1.3 HEIGHT ADJUSTMENT
The
armrest
allows a height adjustment by increment of 1 inch.
To do it (see; figure 37):
1. Unscrew slightly the locking nut and the screw (H) from the (F) armrest lateral
panel, using a 8 mm key and a 4 mm Allen key.
2. Push on the (D) release button in the same direction than the arrow and pull
upwards the armrest by grabbing the (J) armrest upholstery. Adjust the armrest
height as needed. At every step of adjustment you should feel the (D) release
button locking the armrest height in position. This will happen each time you will
reach a new position.
3. Tighten the locking screw and nut (H) to fix permanently the armrest position.
It can be dangerous to raise the wheelchair, while holding it by
the armrests.
