4.5.3 STABILIZER BAR WITH HEADREST SUPPORT
For a better comfort, it is possible to put a headrest on the
wheelchair,
to do this :
1. Cut out the end of the rubber handles on the backrest handle;
2. Using a 5/32" Allen key, tighten the (A) screw at each side of the push bar on the
end of the backrest post that you just took out on step 1 (see; figure 9).
3. Tighten firmly both (A) screws.
Figure 9 : Stabilizer bar (push bar) with headrest support.
BACKREST
POST
PUSH BAR
(A)
SCREW
HEADREST
SUPPORT
