5 OPERATING INSTRUCTIONS

5.8 ANTI-TIPPERS

5.8.1 TO REMOVE

•

In order to facilitate the transportation of your wheelchair, the anti-tippers can

be removed. To do this, exert a pressure on the (A) spring release button

and remove the anti-tipper from its housing (see; figure 53-A).

5.8.2 TO SWINGAWAY

1. To go over some obstacles, the anti-tippers can be swingaway towards the inside

of the frame (see; figure 53-A) ;

2. In this case, a third person must protect against any movements from behind the

wheelchair, near the backrest, both hands in contact with the backrest push

handles.

Never use your wheelchair if the anti-tippers are not

installed.

Figure 53-A : Anti-tippers adjustment.
