5 OPERATING INSTRUCTIONS
inc All rights reserved
64
5.2 ADJUSTABLE « T » SHAPE ARMREST
Figure 38-A : Telescopic armrest adjustment.
The height adjustment of the telescopic armrest is made by an up and down movement.
This movement is activated by a lever positioned under the armrest towards rear (see;
figure 38-A).
Figure 38-B : Lever to adjust height of the "T" shape armrest.
You should pull upwards the lever (see; figure 38-B) to adjust the armrest height as
needed. Release the lever to block the armrest in position.
NOTE
: Once the armrest is adjusted, check if the mechanism is correctly secured in
position, by applying pressure on the armrest upwards or downwards.
LEVER
PULL
UPWARDS
