5 OPERATING INSTRUCTIONS
inc All rights reserved
77
5.6 REAR WHEELS
5.6.1 TO REMOVE AND/OR INSTALL
If your
wheelchair
is equipped with a quick release axle, you can
remove wheels in order to facilitate transportation.
This operation is carried out when nobody is seated in the wheelchair.
To remove the wheel :
1. Push the (A) button and pull the wheel towards you while grabbing the
wheel by its center (see; figure 48) ;
2. To replace, push the (A) button and insert the axle in the housing. Make sure
that the axle is locked in position in the housing by the blocking pins (B).
Figure 48 : Quick release axle.
5.6.2 PNEUMATIC TIRE PRESSURE
In order to guarantee optimum performances from your wheelchair, the tire
pressure must be checked every week.
6 x 1 ¼ inches Tire 35 psi
8 x 1 ¼ inches Tire 35 psi
20 inches Tire 65 psi
22 inches Tire 65 psi
24 inches Tire 65 psi
NOTE
: Make sure that the inflating apparatus will not damage the tire, if a higher
pressure than the one supported by the tire can be reached.
