4 SETUP INSTRUCTIONS
inc All rights reserved
23
4.5.2 CHANGING THE BACKREST HEIGHT
To change the backrest height, unscrew the (A) screw (using a 7/16" wrench)
located on each backrest structure. Choose the height by placing the threaded
hole on the backrest post in line with one of the 5 holes (H1 to H5) on the backrest
structure tubing and then screw back the (A) screw in position. Tighten firmly.
(see; figure 8).
Figure 8 : To change backrest height.
(A)
SCREW
BACKREST
STRUCTURE TUBING
BACKREST
POST
