Orthofab Tango - Page 36

4 SETUP INSTRUCTIONS
inc All rights reserved 36
Figure 18-B : Compartment installed. Figure 18-C : Actuator cable.
Figure 18-D : Actuator and connector. Figure 18-E : Control box and cables.
The batteries
compartment must be
installed just beside the
actuator and the
charger over the frame
cross bar.
(B) FLAP
ACTUATOR
CABLE
