Otoport OAE+ABR
User Manual for Otoport DP+TE model
219
Technical specications
27.5 ABR Module
Note:
The ABR Module has no user serviceable parts. Any required
servicing must be conducted by Otodynamics Ltd or authorised
service facilities only.
27.5.1 Physical
Hand-held module: 278mm x 84mm x 38mm
Weight: 240g (490g with Otoport tted)
27.5.2 Interfaces
Probe connectors compatible with Otodynamics UGS and UGD probes (8 pin)
Electrode connectors compatible with 1.5mm ‘Touchproof’ DIN 42-802 connectors
Charging/Data connector - connects to Otodynamics PSU (charging) or to PC USB
port (USB 1.1or 2.0) via Data Cable
27.5.3 Indicators
Data display: Data is displayed via Otoport (refer to section 23.1)
Probe Fit: Indicators on Otoport:
Noise OK - Blue LED (‘N’)
Stimulus OK - Blue LED (‘S’)
Impedance check: Impedance OK - Green LED
(one for each electrode socket)
Power/Charge: Power OK - Green LED
Fast charge: Amber LED
Audible: Audio feedback via Otoport speaker
