Setting Ethernet communication environment of Communication cassette AFPX-COM5
The Configurator WD is used to set Ethernet communication environment of the AFPX-COM5.
Start the Configurator WD.
Search the AFPX-COM5.
Select the AFPX-COM5 from the search result, and set an IP address to connect with a computer.
After that, search again. Select the AFPX-COM5, and select [Edit] → [Communication Setting] in the
menu, or right-click to select [Communication Setting].
Dialog box of communication setting
Note:
If the TCP is selected for the communication protocol, up to three connections are established using the
computer link (Ethernet), however, when using the programming tool FPWIN GR for connection (using
registration monitor command, multi-frame), more than two connections cannot be established. Also, If
the UDP is selected for the communication protocol, the UDP communication cannot be used as the
programming tool FPWIN GR does not support it, although no restriction on connections.
