Panasonic DP-3510

192
JAN 2006
Ver. 5.2
DP-3510/3520/3530/4510/4520/4530/6010/6020/6030
405 XMT B Transmitter received FTT after it
transmitted TCF at 2400 bps.
Received RTN after
communicating at 2400 bps.
Line quality is poor. (TCF is damaged
due to line noise)
Receiver is defective. (Modem, MJR
PCB, etc.)
FXB PCB or MJR PCB is defective.
406 RCV
(Password
Comm.)
B XMT-Password mismatched. RCV-
Password mismatched. Selective
RCV incomplete.
XMT, RCV password does not match.
Last 4 digits of TSI does not match with
the last 4 digits of Auto Dial telephone
number.
407 XMT D Transmitter received no response
after it transmitted post message,
such as EOP, MPS, EOM, etc...or
received DCN.
Receiver is defective. (No paper, paper
jamming, etc.)
Receiver ceased receiving because of
excessive error. (Line quality is poor)
FXB PCB (Modem) or MJR PCB is
defective.
408 XMT D Transmitter received RTN after it
transmitted EOP, MPS, or EOM.
Receiver receives data with error. (Line
quality is poor)
Receiver is defective. (Modem, MJR
PCB, etc.)
FXB PCB or MJR PCB is defective.
409 XMT D Transmitter receives PIN after it
transmitted a post message, such
as EOP, MPS, EOM, etc.
Receiver receives data with error due to
poor line quality, and receiving operator
requests voice contact.
Receiver is defective. (Modem, MJR
PCB, etc.)
FXB PCB or MJR PCB is defective.
410 RCV D Received DCN while waiting for
post command. (EOP, MPS, EOM,
etc.)
Interface or line is faulty.
Transmitter is defective.
411 RCV
(Polling)
B Received DCN after transmitting
NSC.
Transmitter is not ready for polling
communication.
Password does not match between
transmitter and receiver.
412 G3 RX B, D No response within 12 seconds in
NSS/DCS/MPS wait state. (After
transmitting FTT)
Transmitter is defective.
FXB PCB is defective.
414 RCV
(Polling)
B No response received after
transmitting 3rd NSC.
Password does not match between
transmitter and receiver.
Transmitter is defective. (No original,
document jam, etc.)
415 XMT
(Polling)
B Remote side attempted to receive
message from your machine in
polling communication.
Inform the remote side that your
machine does not have the polling
transmission feature.
416 RCV D Receiver did not detect post
command, such as EOP, MPS,
EOM, etc.
Transmitter is defective.
Line quality is poor. (RTC signal is
distorted due to line noise)
FXB PCB or MJR PCB is defective.
417 RCV C Receiver returned RTN in
response to post message.
Line quality is poor. (There are
excessive errors in received data)
FXB PCB or MJR PCB is defective.
Fax Information Codes
Code Mode Phase Description of Problem Cause
