Panasonic DP-3510 - Page 211

211
JAN 2006
Ver. 5.2
DP-3510/3520/3530/4510/4520/4530/6010/6020/6030
002 Upper Limit Sensor
(2nd Paper Tray)
Upper Limit is detected. 1
NP Sensor
(2nd Paper Tray)
Paper is not detected. 1
Paper Remaining Sensor 3
(2nd Paper Tray)
Sensor is activated. 1
Paper Remaining Sensor 2
(2nd Paper Tray)
Sensor is activated. 1
Paper Remaining Sensor 1
(2nd Paper Tray)
Sensor is activated. 1
Size Sensor 3
(2nd Paper Tray)
Sensor is activated. 1
Size Sensor 2
(2nd Paper Tray)
Sensor is activated. 1
Size Sensor 1
(2nd Paper Tray)
Sensor is activated. 1
003 Toner Bottle Home
Position Sensor
Home position is
detected.
0
Paper Path Sensor
(1st Paper Tray)
Paper is detected. 0
Upper Limit Sensor
(1st Paper Tray)
Upper Limit is detected. 1
NP Sensor
(1st Paper Tray)
Paper is not detected. 1
Paper Remaining Sensor 3
(1st Paper Tray)
Sensor is activated. 1
Paper Remaining Sensor 2
(1st Paper Tray)
Sensor is activated. 1
Paper Remaining Sensor 1
(1st Paper Tray)
Sensor is activated. 1
Paper Path Sensor
(2nd Paper Tray)
Paper is detected. 0
004 Right Cover Open/Close
Sensor
Cover is open. 1
High Voltage Leak
Detection
(Bias)
Normal. 1
High Voltage Leak
Detection
(Separation Corona)
Normal. 1
High Voltage Leak
Detection
(Transfer Corona)
Normal. 1
High Voltage Leak
Detection
(Charge Corona)
Normal. 1
Developer Unit Detecting
Sensor
Developer Unit is not
detected.
1
F4 Mode (Input Check)
No. Function Condition
Message Display
Remarks
76543210
