E7-47 • Paper Pushing Plate Motor (M8S)
• Paper Pushing Plate Home Position
Sensor (PI4S)
• The paper pushing plate home position sensor does
not turn ON even when the paper pushing plate
motor has been driven for 0.3 sec or more.
• The paper pushing plate home position sensor does
not turn OFF even when the paper pushing plate
motor has been driven for 80 msec or more.
• Paper Pushing Plate Motor (M8S)
• Paper Pushing Plate Top Position
Sensor (PI15S)
• The paper pushing plate top position sensor does
not turn OFF even after the paper pushing plate
motor has been driven for 80 msec or more.
• Paper Pushing Plate Motor (M8S)
• Paper Pushing Plate Motor Clock
Sensor (PI1S)
• The number of clock pulses for the paper pushing
plate motor clock sensor drops below a specific
value.
• Paper Pushing Plate Motor (M8S)
• Paper Pushing Plate Top Position
Sensor (PI5S)
• The paper pushing plate top position sensor does
not turn ON when the paper pushing plate motor has
been driven for 0.3 sec or more.
E7-49 • Guide Home Position Sensor (PI13S)
Connector
• The connector of the guide home position sensor is
identified as being disconnected.
• Paper Pushing Plate Home Position
Sensor (PI14S) Connector
• The connector of the paper pushing plate home
position sensor is identified as being disconnected.
• Paper Pushing Plate Top Position
Sensor (PI15S) Connector
• The connector of the paper pushing plate top
position sensor is identified as being disconnected.
E7-50 • Inlet Door Switch (MS1S)
• Front Door Switch (MS2S)
• Delivery Door Switch (MS3S)
• After any of the following three photo-interrupters
used for the covers has found that its respective
door is closed, the inlet door switch is identified as
being open as soon as copying status or 1 sec or
more after the start of the copier initial rotation.
• Inlet cover sensor (PI9S)
• Front door open / closed sensor (PI2S)
• Delivery cover sensor (PI3S)
(The front door switch (MS2S) or the delivery door
switch (MS3S) may be also open.)
• Front Door Switch (MS2S)
• Delivery Door Switch (MS3S)
• After any of the following three photo-interrupters
used for the covers has found that its respective
door is closed, the front door switch is identified as
being open as soon as copying status or 1 sec or
more after the start of the copier initial rotation.
• Inlet cover sensor (PI9S)
• Front door open / closed sensor (PI2S)
• Delivery cover sensor (PI3S)
(The delivery door switch (MS3S) may be also
open.)
• Delivery Door Switch (MS3S) • After any of the following three photo-interrupters
used for the covers has found that its respective
door is closed, the delivery door switch is identified
as being open as soon as copying status or 1 sec or
more after the start of the copier initial rotation.
• Inlet cover sensor (PI9S)
• Front door open / closed sensor (PI2S)
• Delivery cover sensor (PI3S)
Error
Code
Error Type Description
