Panasonic KV-S1025C SERIES User Manual

117
15.2. PANEL Board
15.3. PAPER SENSOR Board
15.4. STARTING SENSOR Board
15.5. DOOR DETECTION Board
L1056 ERJ3GEY0R00 0-ohm Jumper
Q1001 UNR221100L Transistor
Q1002 B1ABCF000011 Transistor
Q1003 B1ABCF000011 Transistor
Q1004 B1ABCF000011 Transistor
Q1005 B1ABCF000011 Transistor
Q1006 B1ABCF000011 Transistor
Q1007 B1ABCF000011 Transistor
Q1008 B1DHGD000024 Transistor
Q1009 B1ABCF000011 Transistor
Q1010 UNR221100L Transistor
Q1011 UNR221100L Transistor
Q1013 UNR211100L Transistor
Q1014 UNR211100L Transistor
Q1016 B1ABCF000011 Transistor
Q1017 B1ABCF000011 Transistor
IC1001 C0JBAZ001411 IC CMOS Logic
IC1002 C0DBGYY00055 IC
IC1003 C0DBGYY00055 IC
IC1004 C0ZBZ0001328 IC
IC1005 C0ZBZ0001328 IC
IC1006 C0DBGYY00056 IC
IC1007 C1CB00002333 IC
IC1008 C3ABPG000145 IC 64M SD RAM
IC1009 C3ABPG000145 IC 64M SD RAM
IC1010 C1DB00001183 IC
IC1011 C3EBEG000059 IC EEPROM
IC1012 C0EBE0000338 IC
IC1013 PPS853CHS01 Flash Memory
IC1014 C0DBEMH00001 IC
IC1015 C0GAY0000010 Motor IC
IC1016 C2CBYY000051 IC
CN1001 K1KA16AA0442 Connector
CN1002 K1KA22AA0442 Connector
CN1005 K1KA02AA0193 Connector
CN1006 K1KA06A00452 Connector
CN1007 K1KA07AA0193 Connector
CN1008 K1KA07AA0618 Connector
JK1001 K1FA104B0036 Connector
JK1002 K2EE2B000003 DC Jack
X1001 H1Z1006B0006 Crystal Resonator
X1002 H0J200200002 Oscillator
X1003 H0J240500020 Crystal Resonator
F1001 K5H402A00010 Fuse
Ref. No. Part No. Part Name & Description Remarks
R5001 ERJ3GEYJ221 220 / J / (1/10W)
R5003 ERJ3GEYJ821 820 / J / (1/10W)
R5004 ERJ3GEYJ821 820 / J / (1/10W)
R5007 ERJ3GEY0R00 0-ohm Jumper
R5008 ERJ3GEY0R00 0-ohm Jumper
R5009 ERJ3GEY0R00 0-ohm Jumper
R5010 ERJ3GEY0R00 0-ohm Jumper
C5001 ECJ1VF1H104Z 0.1 / Z / 50V
D5001 LN38GPX LED
D5002 LN28RPX LED
CN5001 K1KA04BA0061 Connector
SW5001 K0H1BA000401 Switch
LH-5-6 Spacer
Ref. No. Part No. Part Name & Description Remarks
R5005 ERJ3GEYJ221 220 / J / (1/10W)
R5014 ERJ3GEY0R00 0-ohm Jumper
R5015 ERJ3GEY0R00 0-ohm Jumper
R5016 ERJ3GEY0R00 0-ohm Jumper
C5003 ECJ1VF1H104Z 0.1 / Z / 50V
IC5002 B3NAA0000097 Photo Interrupter
CN5003 K1KA03BA0285 Connector
Ref. No. Part No. Part Name & Description Remarks
Ref. No. Part No. Part Name & Description Remarks
R5002 ERJ3GEYJ221 220 / J / (1/10W)
R5011 ERJ3GEY0R00 0-ohm Jumper
R5012 ERJ3GEY0R00 0-ohm Jumper
R5013 ERJ3GEY0R00 0-ohm Jumper
C5002 ECJ1VF1H104Z 0.1 / Z / 50V
IC5001 B3NAA0000097 Photo Interrupter
CN5002 K1KA03BA0150 Connector
Ref. No. Part No. Part Name & Description Remarks
R5006 ERJ3GEYJ221 220 / J / (1/10W)
R5017 ERJ3GEY0R00 0-ohm Jumper
R5018 ERJ3GEY0R00 0-ohm Jumper
R5019 ERJ3GEY0R00 0-ohm Jumper
C5004 ECJ1VF1H104Z 0.1 / Z / 50V
IC5003 B3NAA0000097 Photo Interrupter
CN5004 K1KA03BA0148 Connector
