64
9.2. Service Utility Function
The Service Utility function is as follows.
Note:
When two or more scanners are connected to the PC, execute “Select Scanner” to define the scanner before evaluating.
The procedure is as follows.
1. Click “Select Scanner” on the Main Menu.
2. Select the product number of the scanner to evaluate.
Note:
*1
: These items are included in User Utility software.
*2
: This setting is needed when replacing CONTROL Board or IC1011.
*3
: Available only for KV-S1025C Series
Remarks
(1) Parameter setting by user
(2) Status indication
(3) Parameter setting by service person
(4) Adjustment
(5) Diagnosis
(6) Maintenance
Item Purpose Remarks
Scanner Status
*1
Used to indicate the scanner status (Ready, Error, or Warning) (2)
Scanner Information
*1
Used to indicate the scanner information, such as Model, Firmware Version,
Interface, and etc.
(2)
Scanner Counter
Update All Counters
*1
Used to update the values of System Counter, Cleaning Roller Counter, and
Replacing Roller Counter
(1), (6)
Clear Counter
*1
(After Clean Roller)
Used to reset the Cleaning Roller Counter to zero after cleaning the roller (1), (6)
Clear Counter
*1
(After Replace
“Double-feed
Prevention Roller”)
Used to reset the counter (After Replace “Double-feed Prevention Roller”) to
zero
(1), (6)
Clear Counter
*1
(After Replace “Paper
Feed Roller”)
Used to reset the counter (After Replace “Paper Feed Roller”) to zero (1), (6)
Scanner Condition
Sleep Mode
*1
Used to set this setting to "Enable" or "Disable", and to set "Waiting Time"
before entering the Sleep Mode
(1)
Vertical Line
Reduction
*1
Used to reduce vertical lines on the scanned image caused by a scratch or
dust in the scanning area
(4)
Warning Setting
*1
Used to set the number of document scanning that enables the Service Utility
to inform the warning messages (roller replacement timing and roller
cleaning timing)
(3)
Set Default Used to set the “Sleep Mode” and “Warning Setting" to the default settings (3)
Test LED Used to test the LEDs (Green, Red) on the front panel by turning on/off
periodically
(5)
Key / Sensor Used to perform the Key or Sensor ON/OFF test (5)
Conveyor Motor Used to check Conveyor Motor Rotation (5)
Feed Used to check the paper feed mechanism (5)
Sleep Mode Used to check whether sleep mode function works properly (5)
CCD Level Used to check a maximum peak level after setting CCD gain (5)
Memory Used to execute memory R/W test (5)
Adjust Shading Used to execute shading correction (4)
All Position Used to adjust the scanning length, width, paper-end, vertical, and horizontal
positions for front
*3
(and back) sides, automatically
(4)
Individual Position 1. Used to execute automatic length, width, paper-end, vertical, or horizontal
position adjustment for front (and back)
*3
sides, individually
2. Used to adjust scanning length, width, paper-end, vertical, or horizontal
positions for front (and back)
*3
sides manually
(4)
USB ID
*2
Used to set a USB ID for the scanner connected to the PC (4)
Other
Save Information
*1
Used to save the scanner and PC information (1)
