88
11.2. Block Diagram-2 (Boards)
A
C IN
(100 V to 240 V)
Conveyor Motor
PANEL Board
AC Adaptor
CCD Board (F)
LED
SW
CN5002
JK1002
CN1008 CN1007CN1001 CN1002
CN5001
CN2501
CN1006
USB
STARTING
SENSOR
Board
*1
CCD Board (B)
Lamp Drive
Board (F)
Lamp (F)
*1
Lamp (B)
*1
Lamp Drive
Board (B)
CN5004
CN5003
PAPER
SENSOR
Board
DOOR
DETECTION
Board
DC IN (+16 V)
JK1001
CN2001
CN1005
Power Switch
Note:
*1
For KV-S1025C Series Only
CONTROL Board
