8.5. Required Adjustments After Part Replacement
The following adjustments are required when a circuit board assembly or part is replaced or reassembled.
Action Code: R: Replace A: Reassemble
Circuit Board or Part Action
Code
Required Adjustment Remarks
IC1013 (on CONTROL
Board)
R 1. Adjust Shading.
CONTROL Board or
IC1011 (on CONTROL
Board)
R 1. Adjust Shading. (Only when replacing CONTROL
Board assembly)
2. Adjust All Position.
3. Adjust Individual Position, manually as required.
4. Set USB ID.
*1
STARTING SENSOR
Board
R, A 1. Adjust All Position, or the following adjustment should be
required.
a. Adjust Length in Individual Position.
b. Adjust Paper-end Position in Individual Position.
c. Adjust Front Vertical Position in Individual Position.
d. Adjust Back Vertical Position in Individual Position.
(KV-S1025C Series Only)
*1
Optical Unit (F) R, A 1. Adjust Shading.
2. Adjust All Position, or the following adjustment should be
required.
a. Adjust Front Vertical Position in Individual Position.
b. Adjust Front Horizontal Position in Individual Position.
c. Adjust Front Width in Individual Position.
*1
Optical Unit (B)
(KV-S1025C Series Only)
R, A 1. Adjust Shading.
2. Adjust All Position, or the following adjustment should be
required.
a. Adjust Back Vertical Position in Individual Position.
b. Adjust Back Horizontal Position in Individual Position.
c. Adjust Back Width in Individual Position.
*1
Lamp (F) R, A 1. Adjust Shading.
2. Adjust All Position, or the following adjustment should be
required.
a. Adjust Front Vertical Position in Individual Position.
b. Adjust Front Horizontal Position in Individual Position.
c. Adjust Front Width in Individual Position.
*1
Lamp Drive Board (F) R, A 1. Adjust Shading.
2. Adjust All Position, or the following adjustment should be
required.
a. Adjust Front Vertical Position in Individual Position.
b. Adjust Front Horizontal Position in Individual Position.
c. Adjust Front Width in Individual Position.
*1
Lamp (B)
(KV-S1025C Series Only)
R, A 1. Adjust Shading.
2. Adjust All Position, or the following adjustment should be
required.
a. Adjust Back Vertical Position in Individual Position.
b. Adjust Back Horizontal Position in Individual Position.
c. Adjust Back Width in Individual Position.
*1
Lamp Drive Board (B)
(KV-S1025C Series Only)
R, A 1. Adjust Shading.
2. Adjust All Position, or the following adjustment should be
required.
a. Adjust Back Vertical Position in Individual Position.
b. Adjust Back Horizontal Position in Individual Position.
c. Adjust Back Width in Individual Position.
*1
Reference Area (Front) R 1. Adjust Shading.
Reference Area (Back)
(KV-S1025C Series Only)
R 1. Adjust Shading.
Conveyor Roller R 1. Adjust Length in Individual Position, or adjust All Position. *1
Exit Roller R 1. Adjust Length in Individual Position, or adjust All Position. *1
