CN1006 [CONTROL Board] - [Conveyor Motor]
Pin No. Signal Name Description
CN1006 Motor
Connector
1 1 A Motor Phase A
2 2 *A Motor Phase *A
3 3 *B Motor Phase *B
4 4 B Motor Phase B
5 5 COMA Motor Common A (+16 V)
6 6 COMB Motor Common B (+16 V)
CN1007 [CONTROL Board] /CN5001 [PANEL Board] /Lamp Drive Board (B)
Pin No. Signal Name Description
CN1007 CN5001 Lamp Drive
Board (B)
1 1 - GND Ground
2 2 - *KEY Key signal
3 3 - LED_G Green LED signal
4 4 - LED_R Red LED signal
5- 1GND GND
6 - 2 BLAMP Back Lamp ON
7- 3+16V +16 V
CN1008 [CONTROL Board]/ CN5002 [STARTING SENSOR Board]/ Lamp Drive Board (F)
Pin No. Signal Name Description
CN1008 CN5002 Lamp Drive
Board (F)
1 1 - GND Ground
2 2 - STARTING Starting signal
3 3 - +3.3V +3.3 V
4 - - N.C. Not used
5- 1GND GND
6 - 2 FLAMP Front Lamp ON
7- 3+16V +16 V
JK1001 [CONTROL Board] - USB Interface
Pin No. Signal Name Description
JK1001 -
1 - VBUS USB BUS detection
2 - DM USB Data (-)
3 - DP USB Data (+)
4 - GND Ground
JK1002 [CONTROL Board] - AC Adaptor
Pin No. Signal Name Description
JK1002 -
1 - +16V +16 V
2 - GND Ground
3 - GND Ground
